EZHONG W43C roller levellers fully drive upper and lower main rolls with dual motors, soft start, and emergency braking. Multi-row support rolls and mill-type needle bearings help correct wave and scoop deformation on thin to medium plate.
EZHONG W43C roller levellers fully drive upper and lower main rolls with dual motors, soft start, and emergency braking. Multi-row support rolls and mill-type needle bearings help correct wave and scoop deformation on thin to medium plate.
The EZHONG W43C plate straightening / roller leveller series targets plants that need reliable correction of waves, scoop shapes, and residual stress patterns after cutting, welding, or rolling.
Upper and lower main rolls are fully driven by two motors, with emergency braking and soft start to reduce grid impact and noise. The depressing-corner and corner mechanisms share group technology with YEJ motors so the movable beam can position accurately and swivel quickly.
Upper and lower supporting rolls use multi-row diameter supports arranged in a chessboard pattern with the work rolls. An integral inclined-iron mechanism fine-tunes roll shape. Work-roll journals use rolling-mill self-aligning needle bearings for lower friction and better thin-plate grip than copper sleeves.
EZHONG states that W43C development absorbed German and Japanese leveler practice and, since 1994, transplanted control technology from its large CNC bending machines into roller levelers—creating a family of products with independent intellectual property.
Role of the W43C series The EZHONG W43C plate straightening / roller leveller series targets plants that need reliable correction of waves, scoop shapes, and residual stress patterns after cutting, welding, or rolling. Drive and control Upper and lower main rolls are fully driven by two motors, with emergency braking…
Manufacturer: Hubei Heavy Industry Equipment Co., Ltd. (EZHONG). Campus: 200,000 m² in Ezhou, Hubei, China.
EZHONG W43C roller levellers fully drive upper and lower main rolls with dual motors, soft start, and emergency braking. Multi-row support rolls and mill-type needle bearings help correct wave and scoop deformation on thin to medium plate.
Use the contact form and identify the W43C Leveling Machine. EZHONG will confirm the current configuration and the information needed for this product.
EZHONG supplies heavy plate forming equipment for export projects and has delivered systems to 30+ countries and regions. Contact sales for logistics, FAT, and installation guidance.
Related models from the same product family.
EZHONG W43T plate levelers straighten medium and heavy steel plate with patented sub-roller drive and CNC pressing calculation. Published examples include 40×3000 mm and 80×3000 mm models, plus a large EZW43T-120×3000 mm (400 MPa) reference unit.
EZHONG W43B plate levelers use a six-upper and seven-lower straightening roll layout with spring-loaded feed rolls and fine-tuned middle rolls. Example published model EZW43B-10×3000 levels about 10 mm plate at 3000 mm width.
