Product Family
Press Machine
Industrial hydraulic presses and horizontal axle presses for heavy component pressing and railway bearing assembly applications.
2 Models
Product Family Overview
Available Models
Review the published configurations in this family and open the full detail page for specifications and application fit.
Hydraulic Press
EZHONG hydraulic presses use independent power and electrical systems with PLC button control for inching and semi-automatic cycles. A published 500T example runs at 25 MPa with 800 mm stroke and 44 kW motor power.
Example model 500TMax working pressure 25 MPa; effective stroke 800 mm; max opening height 1600 mm; pressing speed 10–15 mm/s; motor power 44 kW
ControlIndependent power and electrical systems; PLC process control; fixed-stroke and fixed-pressure modes
Full Specifications→
Horizontal Axle Press Machine
EZHONG horizontal axle (wheel) presses cold-press rolling bearings onto railway wheel journals. The published EZY92-3150KN model delivers 3150 kN nominal pressure with 600 mm stroke and 0–4 mm/s pressing speed.
Example model EZY92-3150KNNominal pressure 3150 kN; max stroke 600 mm; max gear axle diameter 1300/350; pressing speed 0–4 mm/s; dimensions 5360×1200×2400 mm
ApplicationsMetallurgy, mine machine repair, machine manufacturing, large motor manufacturing; press-fitting/disassembly of large shaft parts
Full Specifications→
